Application Areas:
DIAMENSIONS
Design impressive acoustic pictures yourself
DIAMENSIONS
Design impressive acoustic pictures yourself
Three-colour acoustic sets for creative room design
- Acoustic core in anthracite, coloured acoustic felt surface
- 8 different colour versions, each consisting of three colours
- Acoustic murals with and without 3D effect easy to design yourself!
- Ideal for acoustic optimisation in offices, meeting rooms, living rooms, doctor's offices, law firms, schools, nurseries, and much more
- Contour cut in diamond shape, side length approx. 24 cm each (height ~ 41,5 cm, width 24 cm)
Loading...
Adjust room
Impressions
DIAMENSIONS – A diamond for good acoustics
- Diamond-shaped sound absorber with fine felt surface and acoustic foam core
- Low-maintenance textile surface in 20 attractive colour variants
- Highly effective broadband absorber for a creative, modern space design
Product data
Format, surface
contour cut in diamond shape: each side with the length of 24 cm (height ~ 41,5 cm, width 24 cm), acoustic foam core with textile felt surface
Material thicknesses
3 cm, 5 cm, 8 cm
Material
Open-cell PUR acoustic foam with acoustic felt lamination
Content
Pack of 36 = 12 elements per color
Pack of 72 = 24 elements per color
Colours
Acoustic core in anthracite
Surface made of coloured acoustic felt (depending on colour version)
-
- marbled light grey
- black
- ash grey
-
- marbled light grey
- sky blue
- Royal blue
-
- marbled light grey
- may green
- marbled forest green
-
- marbled light grey
- designred
- ash grey
-
- marbled light grey
- Marbled sandstone
- marbled cream white
-
- marbled amber
- Marbled sandstone
- marbled cream white
-
- marbled lavender
- marbled blackberry
- sunny yellow
-
- marbled lavender
- Sky blue
- sunny yellow
Can’t find the right colours? No problem!
With our FORMS Diamond sound absorber, you can customise the colours you want!
Fire classes
PUR-E (without flame protection), PUR-E+ (FMVSS302), PUR-E++ (DIN 4102 B2) (only with aixFOAM STICKY)
The fire classes of the aixFOAM absorbers do not only refer to the material, but always include the products including the mounting options offered by us, such as our STICKY self-adhesive kit.
More information about the fire classes of our sound absorbers is available the relevant aixFOAM knowledge article.
Fastening options
STICKY. Makes your aixFOAM self-adhesive.
Temperatureresistance
- 40 °C to + 100 °C
Harmful substance information
Mineral fibre free
Tolerance
This high quality acoustic product is made on our precision machinery according to DIN 7715 Part 5 P3.
More information about this product is available, if required, in the accompanying datasheet. We are happy to provide you with this upon request.
Absorption values
The measurements of the absorption coefficient were performed on PUR-ES acoustic foams from RWTH Aachen. All values refer to absorbers with a size of 100 cm x 50 cm and were calculated according to DIN 52212.
 Frequency range |
 Height 3 cm |
 Height 5 cm |
 Height 8 cm |
|---|---|---|---|
| 125 Hz | 0,10 | 0,17 | 0,23 | 250 Hz | 0,50 | 0,73 | 0,75 |
| 500 Hz | 0,78 | 0,71 | 0,73 |
| 1000 Hz | 0,63 | 0,59 | 0,64 |
| 2000 Hz | 0,49 | 0,57 | 0,59 |
| 4000 Hz | 0,53 | 0,45 | 0,70 |
Our aixFOAM sound absorbers have been tested for Hertz and pores in the reverberation chamber of renowned institutions such as RWTH University or the Technical University in Aachen. The sound absorption coefficients according to DIN 52212 stated above were calculated in extensive measurements.
Profit from sound insulation directly from the manufacturer!
At aixFOAM we make sound insulation for applications in room acoustics and technical acoustics. And because we do this particularly well, we have been doing it for 65 years. Over this time we have been constantly working on the further development of our products and therefore are able to offer you highly effective sound absorbers in a modern design.
Our aixFOAM philosophy: We combine customer-oriented advice with the individual, needs-based production of sound insulation solutions. Or in other words: We help you with free advice to find the ideal sound insulation for your project and start to make your absorbers directly after receiving your order. You then receive your sound insulation directly from the factory – naturally in the best quality.
- Use of high quality acoustic foams from Germany
- Precision manufacturing on the latest CNC cutting machines and systems
- Standard solutions or individual small and series manufacturing of noise insulation
- Advice, planning, production and brokering of assembly partners
Brand quality
from the manufacturer
"Made in Germany"
"Made in Germany"
Production
for you, individually
in a few days
in a few days
Experience
for 65 years
soundproofing experts
soundproofing experts
Award
ISO 9001:2015 certified
‘Our DIAMENSIONS is a great acoustic element for interior design. Its shape allows for interesting pattern arrangements that achieve a 3D effect by combining several colours. With this broadband absorber, every acoustic measure becomes a customised work of art.’
Oliver Solbach, customer advisor
